The HPM line is an horizontal multistage pump range with “ring section” design. Both pump flanges are radial design. This range is equipped with oil lubricated bearings, gland-packing seal type and it is suitable for pressure applications up to 64 Bar. Special materials and seal executions are available on demand. Water booster sets, irrigation systems, Boiler Feed, “RO” systems, geothermal plants are the most common applications.
| Title | Description |
|---|---|
| Pump body | cast iron / AISI 316 / Duplex |
| Pump shaft | AISI431 / AISI 316 / Duplex |
| Pump bearings lubrication | oil |
| Seal type standard | packing |
| Seal type on request | Graf./SIC/EPDM unbalanced or balanced |
| Ambient temperature | -10 - 90 °C - until 120°C with estate mechanics |
