Peripheral positive displacement pump with front suction (PM) and side suction with self-priming system (PM A) for small household systems and simple industrial applications; characterised by a considerable ratio between performance and required output.
| Title | Description |
|---|---|
| Pump body | cast iron, bronze (45BR) |
| Motor bracket | cast iron, cast iron or bronze (45BR); aluminum with inserto AISI304 |
| Impeller | brass |
| Seal | ceramic-graphite-NBR |
| Pump shaft end | steel AISI 416 |
| Ambient temperature | 0 - 90 °C |
| Pump body gasket | max 6 bar (45,50) max 8 bar (65, 80) max 9 bar (90) |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz 1~ 230V-50Hz |
| Insulation class | F |
| Protection degree | IPX4 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| PM 45 | PMT 45 | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| PM 45 BR | PMT 45 BR | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| PM 45 A | PMT 45 A | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| PM 65 | PMT 65 | 0.7 | 0.5 | 5 ÷ 45 | 48.8 ÷ 11.6 |
| PM 65 A | PMT 65 A | 0.7 | 0.5 | 5 ÷ 45 | 48.8 ÷ 11.6 |
| PM 80 | PMT 80 | 1 | 0.74 | 5 ÷ 50 | 61 ÷ 18 |
| PM 80 A | PMT 80 A | 1 | 0.74 | 5 ÷ 50 | 61 ÷ 18 |
| PM 90 | PMT 90 | 1 | 0.74 | 5 ÷ 40 | 79.2 ÷ 8.8 |
| PM 50 | - | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| PM 65 | PMT 65 | 0.7 | 0.5 | 5 ÷ 45 | 48.8 ÷ 11.6 |
| PM 65 A | PMT 65 A | 0.7 | 0.5 | 5 ÷ 45 | 48.8 ÷ 11.6 |
| PM 80 | PMT 80 | 1 | 0.74 | 5 ÷ 50 | 61 ÷ 18 |
| PM 80 A | PMT 80 A | 1 | 0.74 | 5 ÷ 50 | 61 ÷ 18 |
| PM 90 | PMT 90 | 1 | 0.74 | 5 ÷ 40 | 79.2 ÷ 8.8 |
| PM 45 | PMT 45 | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| PM 45 BR | PMT 45 BR | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
| PM 50 | - | 0.5 | 0.37 | 5 ÷ 40 | 35 ÷ 5 |
