Residential
Fully automatic fixed speed booster sets consisting of 2 pumps.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | cast iron , bronze , AISI 316 |
| Mechanical seal | ceramic-graphite-NBR |
| Liquid temperature | -10 ÷ 90 °C |
| Manifold | galvanized iron |
| Control panel | 3~ EQ2SMT ≤ 15kW, 3~ Q2ST > 15kW |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz ≤ 4kW, 3~ 400/690V-50Hz > 4kW |
| Insulation class | F |
| Protection degree | IPX5 |
