Overview

Submersible multistage centrifugal pumps for 4” wells, featuring independent floating impellers that reduce axial load on the motor and prevent wear in case of dry running. The pump bracket is designed for coupling with motors according to NEMA standards. Common applications include civil and agricultural use. The pump materials are certified for drinking water, and due to their high efficiency and reliability, these pumps are highly recommended for residential applications and irrigation. The pumps are ideal for automatic water distribution in combination with pressure tanks, irrigation systems, and other uses.

CONSTRUCTION FEATURES

Title Description
Suction and delivery outlet stainless steel AISI 304
External jacket stainless steel AISI 304
Upper bushings polyoxymethylene and ceramic
Pump shaft stainless steel AISI431B
Impeller, diffuser polyoxymethylene, AISI304
Liquid temperature 45 °C
Quantity of sand in the water 250 g/m³

Motor
