Horizontal centrifugal stainless steel monobloc pump. Widely used in water supplies, pressurization, cooling, and industrial applications. The pump guarantees constant pressure at the variation of flow rates.
| Title | Description |
|---|---|
| Pump body | steel AISI 304 |
| Motor bracket | cast iron |
| Impeller | steel AISI 304 |
| Mechanical seal | ceramic-graphite-NBR |
| Mechanical seal housing | steel AISI 304 |
| Pump shaft end | steel AISI 304 |
| Liquid temperature | -10 ÷ +90°C |
| Operating pressure | max 10 bar |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz P≤4kW 3~ 400/690V-50Hz P>4kW 1~ 230V-50Hz |
| Insulation class | F |
| Protection degree | IPX5 |
