Residential
Single-channel centrifugal drainage pump. Specifically designed for heavy duty applications it guarantees high capacity at medium head; ideal for civil and industrial applications. Available in mobile or permanent version with coupling feet.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | cast iron |
| Seal | double seal with oil barrier: pump side silicon carbide, engine side sealing ring |
| Pump shaft end | steel AISI 304 |
| Prefilter sieve | Ø max 60 mm (DMT 250/4-400/4), Ø max 90 mm (DMT 550/4-750/4) |
| Ambient temperature | 0-40 °C |
| G | rubber NBR |
| Gaskets | stainless steel A2 |
| Bolts | galvanized iron |
| STAINER | 20 m |
| Title | Description |
|---|---|
| 2 poles induction motor in oil bath | 3~ 230V-50Hz, 3~ 400V-50Hz, 3~ 230/400V-50Hz, 3~ 400/690V-50Hz |
| Insulation class | F |
| Protection degree | IPX8 |
