Domestic
Drainage pumps made of corrosion-resistant material for emptying cesspits, cisterns and for gardening. The single-phase version with built-in capacitor and thermal protector can be equipped with a float switch.
| Title | Description |
|---|---|
| Pump body | polypropylene |
| Impeller | noryl® |
| Seal | double lip seal |
| Pump shaft end | steel AISI 416 with ceramic bushing |
| Prefilter sieve | Ø max 4 mm (40-60); Ø max 7 mm (80-100) |
| Ambient temperature | 0-40 °C |
| Quantity of sand in the water | H05 RN8F, 10 m (40/60), H07 RN8F, 10 m (80/100) |
| Number of startups/hr | floating |
| STAINER | 5 m |
| Title | Description |
|---|---|
| 2 poles induction motor | 1~ 230V-50Hz with thermoprotector |
| Insulation class | F |
| Protection degree | IPX8 |
