Self priming pump for pools with a large builtin pre-filter, which, together with the excellent hydraulic performance of the pump, generates a very high filtration capacity. The transparent polycarbonate lid easily allows inspection of the pre-filter sieve. Pump body, seal housing and diffuser reinforced with glass fibre polypropylene are resistant to chemical products used for pools and guarantee excellent duration.
| Title | Description |
|---|---|
| Pump body lid and diffuser | polypropylene |
| Motor bracket | alluminum |
| Impeller | noryl® |
| Mechanical seal | ceramic-graphite-AISI 316 |
| Motor shaft | stainless steel AISI 316 |
| Liquid temperature | max 40 °C |
| Pre-filter | polycarbonate |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz, 1~ 230V-50Hz |
| Insulation class | F |
| Protection degree | IP55 |
