Multi-stage centrifugal pumps that guarantee high pressure. Particularly suitable for civil and industrial applications – in particular pressurisation systems, fire fighting systems and washing plant.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Motor bracket | cast iron |
| Impeller | brass |
| Seal | ceramic-graphite-NBR |
| Pump shaft end | steel AISI 304 |
| Ambient temperature | -10 ÷ +90 °C |
| Pump body gasket | max 30 bar |
| Title | Description |
|---|---|
| 2 or 4 poles induction motor | 3~ 230/400V-50Hz P≤ 4kW, 3~ 400/690V-50Hz P>4kW |
| Insulation class | F |
| Protection degree | IPX5 |
