Residential
Fully automatic fixed speed booster sets consisting of 2 pumps.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | noryl® , brass |
| Mechanical seal | ceramic-graphite-NBR |
| Motor shaft | AISI 303 |
| Liquid temperature | 0 ÷ 50 °C |
| Manifold | galvanized iron |
| Control panel | 1~ EQ2SM , 3~ EQ2SMT |
| Title | Description |
|---|---|
| 2 poles induction motor | 1~ 230V-50Hz , 3~ 230/400V-50Hz |
| Insulation class | F |
| Protection degree | IPX4 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| 2MB150 | 2MBT150 | 2x2 | 2x1.5 | 80 ÷ 400 | 40.2 ÷ 18 |
| 2MB200 | 2MBT200 | 2x2 | 2x1.5 | 80 ÷ 400 | 45.6 ÷ 25.8 |
| 2MB300 | 2MBT300 | 2x3 | 2x2.2 | 80 ÷ 400 | 49.4 ÷ 31.1 |
