Overview

The new electronic system for pumps EASY Control applicable to the POOL2 Series is an integral system to command the installation. By attaching a digital switchboard control panel to the pump, allows an easy and intuitive installation and complete control of the pool. The system incorporates the necessary protections for the pump and for people, time clocks and input / outputs for the management of the lighting system, salt chlorinator, heat pump, temperature probe, etc.

CONSTRUCTION FEATURES

Title Description
Pump body polypropylene
Motor bracket aluminum
Impeller noryl®
Mechanical seal ceramic-graphite-AISI 316
Motor shaft stainless steel AISI 316
Liquid temperature max 40 °C
Pre-filter polycarbonate

Motor

Title Description
2 poles induction motor 1~ 230V-50Hz, 3~ 230/400V-50Hz
Insulation class F
Protection degree IP55
