6”, 8”, 10” rewindable submersible water-filled motors with NEMA coupling flange. Power from 4 kW up to 185 kW. Avaible in PPC (standard), LPE and PE2+PA. The motor can be supplied in AISI 304, AISI 316 or DUPLEX.
| Title | Description |
|---|---|
| Intermediate shaft guiding stage bush | estate to lip (to request estate mechanics) |
| Mechanical seal | stainless steel AISI 431 - (R-RS), stainless steel AISI 316 - (RX), Duplex - (RD) |
| Upper/bottom support External jacket | G25 (R) stainless steel AISI 304 (RS), stainless steel AISI 316 (RX), DUPLEX (RD) |
| Ball bearings | radials and axial (lubricated to waterfall) |
| STAINER | 350 m |
| Title | Description |
|---|---|
| Asynchronous 2 poles rewindable in water filled | 3~ 3x380V ± 10% - 60Hz, 3~ 3x380/660V ± 10% - 60Hz |
| Cooling Flow | min 0,5 m/s |
| Insulation class | Y |
| Insulation | PE2+PA (P) |
| Protection degree | IP68 |
