Residential
High-flow self-priming pool pump available at 4 poles up to 10 HP ideal for quite operation and larger filtration. Cataphoresis painting, screws in AISI316 and pump body in polypropylene with glass fiber give a remarkable resistance to corrosion. In addition, a large support base make the whole system particularly robust.
| Title | Description |
|---|---|
| Pump body | polypropylene + fiber glass |
| Motor bracket | aluminum |
| Impeller | noryl®, marine bronze on request |
| Mechanical seal | ceramic-graphite-AISI 316 |
| Motor shaft | stainless steel AISI 316 |
| Liquid temperature | max 40 °C |
| Pre-filter | polycarbonate |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230V/400V-50Hz, 3~ 400V/690V-50Hz |
| Insulation class | F |
| Protection degree | IP55 |
