Bare shaft centrifugal pump constructed to EN 733 standards; widely used in water supply, pressurisation and fire-fighting systems.
| Title | Description |
|---|---|
| Pump body | steel AISI 316 |
| Motor bracket | cast iron |
| Impeller | steel AISI 316 |
| Intermediate shaft guiding stage bush | mechanics ceramic-graphite-NBR or graphite impregnated cotton packing |
| Mechanical seal | steel AISI 316 |
| Ambient temperature | -10 ÷ +90 °C |
| Pump body gasket | max 10 bar, max 14 bar (... -315 ~ 2900 r.p.m.) |
| Title | Description |
|---|---|
| Motor | Available with IE3 efficency class motor or standard |
