Monobloc horizontal centrifugal pump, constructed in compliance with EN 733 standards, with stub-shaft and bracket for coupling to standard motors; widely used in water supplies, pressurisation and fire-fighting systems; standard supply with counter-flange.
| Title | Description |
|---|---|
| Pump body | steel AISI 316 |
| Motor bracket | cast iron |
| Impeller | steel |
| Seal | ceramic-graphite-NBR |
| Mechanical seal | steel AISI 316 |
| Ambient temperature | -10 ÷ +90 °C |
| Pump body gasket | max 10 bar |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 400/690V - 50Hz |
| Insulation class | F |
| Protection degree | IPX5 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| CMGX100-250B | 100 | 75 | 2000 Ă· 5500 | 83.7 Ă· 67.6 | |
| CMGX100-250A | 125 | 90 | 2000 Ă· 6000 | 93.9 Ă· 70.8 | |
| CMGX80-250B | 60 | 45 | 1600 Ă· 3750 | 80 Ă· 58.8 | |
| CMGX80-250A | 74 | 55 | 1600 Ă· 4000 | 92.8 Ă· 65.2 | |
| CMGX100-200B | 60 | 45 | 1800 Ă· 5500 | 56.8 Ă· 39.7 | |
| CMGX100-200A | 74 | 55 | 1800 Ă· 6000 | 62.2 Ă· 42.5 | |
| CMGX100-250C | 100 | 75 | 2000 Ă· 5500 | 83.7 Ă· 67.6 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| CMGX80-250B | 60 | 45 | 1600 Ă· 3750 | 80 Ă· 58.8 | |
| CMGX80-250A | 74 | 55 | 1600 Ă· 4000 | 92.8 Ă· 65.2 | |
| CMGX100-200B | 60 | 45 | 1800 Ă· 5500 | 56.8 Ă· 39.7 | |
| CMGX100-200A | 74 | 55 | 1800 Ă· 6000 | 62.2 Ă· 42.5 | |
| CMGX100-250C | 100 | 55 | 2000 Ă· 5000 | 73.2 Ă· 61 | |
| CMGX100-250B | 100 | 75 | 2000 Ă· 5500 | 83.7 Ă· 67.6 | |
| CMGX100-250A | 125 | 90 | 2000 Ă· 6000 | 93.9 Ă· 73.2 |
