Drainage pumps with set-back Vortex type impeller for pumping sewage waters and liquids with suspended solids; ideal for civil and household applications. The single-phase version includes a built-in capacitor, a thermal protector and it can be equipped with a float switch.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | vortex type stainless steel (80-102); brass (150) |
| Seal | double estate with barrier d'oil: pump side with silicon carbide mechanical seal; motor side with sealing ring (80-102) or estate mechanics in ceramic-graphite (150) |
| Pump shaft end | stainless steel |
| Prefilter sieve | Ø max 35 mm (80-100), Ø max 50 mm (82-150) |
| Ambient temperature | 0-40 °C |
| Quantity of sand in the water | H07 RN8F, 10 m |
| Number of startups/hr | floating |
| STAINER | 5 m |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 220/380V-60Hz, 1~ 220V-60Hz with thermal protection |
| Insulation class | F |
| Protection degree | IPX8 |
