| Title | Description |
|---|---|
| Lenght | cast iron |
| Frame | 50/60 Hz |
| Multiple voltage/Multi-frequency | Continuo S1 |
| Duty service | tropicalized winding with reinforced insulation for inverters (P ≥ 110 kW optional insulated bearings are recommended). windings with 3 thermistors PTC of series |
| Winding | available in version: || 3G Ex Na IIB T4 Gc, || 3D Ex tc IIIB T125°C Dc |
| Title | Description |
|---|---|
| Motor | chiuso autoventilato |
| Insulation class | F (on request H) |
| Protection degree | IPX5 (on request IP56, IP66, IP67) |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| 132S-4 | 7.5 | 5.5 | |||
| 132M-4 | 10 | 7.5 | |||
| 160M-4 | 15 | 11 | |||
| 160L-4 | 20 | 15 | |||
| 315M-4 | 180 | 132 | |||
| 315LA-4 | 215 | 160 | |||
| 315LB-4 | 270 | 200 | |||
| 355M-4 | 335 | 250 | |||
| 355L-4 | 423 | 315 | |||
| 400M-4 | 483 | 355 | |||
| 180M-4 | 25 | 18.5 | |||
| 180L-4 | 30 | 22 | |||
| 200L-4 | 40 | 30 | |||
| 225S-4 | 50 | 37 | |||
| 225M-4 | 60 | 45 | |||
| 250M-4 | 75 | 55 | |||
| 280S-4 | 100 | 75 | |||
| 280M-4 | 125 | 90 | |||
| 315S-4 | 150 | 110 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| 132M-4 | 10 | 7.5 | |||
| 160M-4 | 15 | 11 | |||
| 160L-4 | 20 | 15 | |||
| 180M-4 | 25 | 18.5 | |||
| 180L-4 | 30 | 22 | |||
| 200L-4 | 40 | 30 | |||
| 225S-4 | 50 | 37 | |||
| 225M-4 | 60 | 45 | |||
| 132S-4 | 7.5 | 5.5 | |||
| 355L-4 | 423 | 315 | |||
| 400M-4 | 483 | 355 | |||
| 250M-4 | 75 | 55 | |||
| 280S-4 | 100 | 75 | |||
| 280M-4 | 125 | 90 | |||
| 315S-4 | 150 | 110 | |||
| 315M-4 | 180 | 132 | |||
| 315LA-4 | 215 | 160 | |||
| 315LB-4 | 270 | 200 | |||
| 355M-4 | 335 | 250 |
