Volumetric pump with liquid ring impeller that gives considerable suction power to the pump. Particularly suitable for liquid transfer (including volatile liquids). The model has a brass front cover thus avoiding the risk of blockage.
| Title | Description |
|---|---|
| Pump body | cast iron and brass |
| Motor bracket | cast iron |
| Impeller | brass |
| Seal | ceramic-graphite-NBR |
| Pump shaft end | steel AISI 416 |
| Ambient temperature | 0 - 90 °C |
| Pump body gasket | max 8 bar |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz, 1~ 230V-50Hz |
| Insulation class | F |
| Protection degree | IPX4 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| MD 75 | MDT 75 | 0.8 | 0.59 | 5 Ă· 45 | 46 Ă· 6 |
| MD 100 | MDT 100 | 1 | 0.74 | 5 Ă· 45 | 53 Ă· 9 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| MD 75 | MDT 75 | 0.8 | 0.59 | 5 Ă· 45 | 46 Ă· 6 |
| MD 100 | MDT 100 | 1 | 0.74 | 5 Ă· 45 | 53 Ă· 9 |
