Overview

New range of pool pumps that include variable speed drive of easy and intuitive setup and high efficiency IE5 synchronous motor with permanent magnets. The combination of these two innovative technologies, assure energy savings up to 80% compared to the traditional pumps. The pump is extremely silent (≈ 40 dB) and has great versatility as one single model is suitable for pools of size from 15 m3 to 450 m3.

CONSTRUCTION FEATURES

Title Description
Pump body polypropylene
Motor bracket aluminum
Impeller noryl
Mechanical seal ceramic-graphite-AISI 316
Motor shaft stainless steel AISI 316
Liquid temperature max 40 °C
Pre-filter polycarbonate

Motor

Title Description
2 poles induction motor 1~ 230V-50Hz
Insulation class F
Protection degree IP55
