Horizontal, self-priming, multistage centrifugal pump, particularly suitable for small and medium-sized pressurization systems; capable of sucking liquids mixed with air.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Engine mount | cast iron |
| Impeller | Noryl® |
| Mechanical seal | ceramic-graphite-NBR |
| Crankshaft | AISI 416 steel |
| Liquid temperature | 0 - 50 °C |
| Operating pressure | max 11 bar |
| Title | Description |
|---|---|
| 2-pole induction motor | 3~ 230/400V-50Hz 1~ 230V-50Hz (with thermal protection) |
| Insulation class | F |
| Degree of protection | IPX4 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| MP 80/3A | MPT 80/3A | 0.8 | 0.59 | 20 ÷ 80 | 29.5 ÷ 13 |
| MP 100/4A | MPT 100/4A | 1 | 0.74 | 20 ÷ 80 | 40 ÷ 18 |
| MP 120/5A | MPT 120/5A | 1.2 | 0.88 | 20 ÷ 80 | 51.5 ÷ 22 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) | H (m) |
|---|---|---|---|---|---|
| MP 80/3A | MPT 80/3A | 0.8 | 0.59 | 20 ÷ 80 | 29.5 ÷ 13 |
| MP 100/4A | MPT 100/4A | 1 | 0.74 | 20 ÷ 80 | 40 ÷ 18 |
| MP 120/5A | MPT 120/5A | 1.2 | 0.88 | 20 ÷ 80 | 51.5 ÷ 22 |
