Stainless steel multistage horizontal pumps. Pumping of clean non-loaded fluids, pressurizing system, irrigation, drinking and glycol water, water treatment, heating and air conditioning, washing system.
| Title | Description |
|---|---|
| Pump body | steel AISI 304 |
| Motor bracket | aluminum |
| Impeller | steel AISI 304 |
| Seal | ceramic-graphite-EPDM ≤ 6 impellers, graphite-silicon carbide-EPDM ≥ 7 impellers |
| Pump shaft end | steel AISI 304 |
| Ambient temperature | -15 ÷ +110 °C |
| Pump body gasket | max 8,5 bar |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz, 1~ 230V-50Hz with thermoprotector up to 1.85 kW |
| Insulation class | F |
| Protection degree | IPX4 |
