Drainage pump with open impeller for pumping liquids with suspended solids, characterised by a high head. The single-phase version with built-in capacitor and thermal protector can be equipped with a float switch.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | brass |
| Shell, motor cover, base support | stainless steel |
| Mechanical seal | double seal with oil barrier: pump side silicon carbide, engine side sealing ring |
| Motor shaft | steel AISI 430 |
| Passage of solids | Ø max 10 mm |
| Liquid temperature | 0-40 °C |
| Cable | H07 RN8F, 10 m |
| G | floating |
| Max Depth of immersion | 5 m |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 220/380V-60Hz, 1~ 220V-60Hz with thermal protection |
| Insulation class | F |
| Protection degree | IP68 |
