Drainage pump with set-back Vortex type impeller for pumping charged waters and liquids with suspended solids; ideal for civil and household applications. The single-phase version with built-in capacitor and thermal protector can be equipped with a float switch.
| Title | Description |
|---|---|
| Pump body | stainless steel with vents from 1” 1/2 or 2” |
| Impeller | vortex type recessed stainless steel |
| Shell, motor cover, base support | stainless steel |
| Seal | double seal with oil barrier: pump side silicon carbide, engine side sealing ring |
| Pump shaft end | steel AISI 430 |
| Prefilter sieve | Ø max 28 mm |
| Ambient temperature | 0-40 °C |
| Quantity of sand in the water | H07 RN8F, 10 m |
| Number of startups/hr | floating |
| STAINER | 5 m |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 220/380V-60Hz, 1~ 220V-60Hz with thermal protection |
| Insulation class | F |
| Protection degree | IPX8 |
