12” – 14” submersible rewindable water-filled motors. Power from 185 kW up to 400 kW. Standard PE2+PA winding, for temperatures up to 30°C.
| Title | Description |
|---|---|
| Upper / bottom support | GG25 or stainless steel AISI 316 |
| External jacket | stainless steel AISI 316 |
| Pump shaft end | stainless steel |
| Mechanical seal | SIC/SIC/NBR |
| Bearings | steel/NBR |
| Title | Description |
|---|---|
| Asynchronous 2 poles rewindable in water filled | 3~ 380-400V ± 10% - 50Hz |
| Cooling Flow | min 0,5 m/s |
| Insulation class | F |
| Insulation | PE2+PA |
| Protection degree | IP68 |
