Residential
Fully automatic variable speed booster sets consisting of 3 pumps.
| Title | Description |
|---|---|
| Shell | AISI 304 , AISI 316 (HX) |
| Pump body | cast iron , AISI 304 (SLX) , AISI 316 (HX) |
| Impeller, diffuser | noryl® (L) , AISI 304 (SL, HS) , AISI 316 (HX) |
| Mechanical seal | ceramic-graphite-EPDM , graphite-SiC-EPDM |
| Liquid temperature | +5 ÷ 35 °C noryl®, -15 ÷ 110 °C AISI 304-316 |
| Manifold | galvanized iron |
| Variable speed drive | 3~ EPIC-to |
| Title | Description |
|---|---|
| 2 poles induction motor | 3~ 230/400V-50Hz ≤ 4kW, 3~ 400/690V-50Hz > 4kW |
| Insulation class | F |
| Protection degree | IPX4, IPX5 ≥ 4,5 HP |
