6” rewindable oil filled submersible motors characterized by high torque, strong mechanical structure, high reliability. Suitable for vertical and horizontal operations.
| Title | Description |
|---|---|
| Motor shaft | NEMA standard |
| Ambient temperature | max 35° C |
| Quantity of sand in the water | from 1,75 to 4 m based on engine size (3 wires + earth) |
| External jacket | cast iron nickel-plated |
| Upper support | stainless steel |
| External Jacket, shaft and cup | ceramic-graphite |
| Mechanical seal | axial and radial oil lubrication |
| On request | max 30 |
| STAINER | 150 m |
| Title | Description |
|---|---|
| Asynchronous 2 poles rewindable in oil bath | 1~ 220/230V-60Hz, 3~ 380/415V-60Hz |
| Insulation class | F |
| Protection degree | IPX8 |
