Drainage pump for charged liquids with set-back Vortex type impeller for civil and industrial applications; specifically designed for very heavy use; available in the mobile or permanent versions with coupling feet.
| Title | Description |
|---|---|
| Pump body | cast iron |
| Impeller | cast iron |
| Seal | double seal with oil barrier: pump side silicon carbide, engine side sealing ring |
| Pump shaft end | steel AISI 304 |
| Prefilter sieve | Ø max 50 mm (DV160-310; 750-1000), Ø max 45 mm (DV400-550) |
| Ambient temperature | 0-40 °C |
| G | rubber NBR |
| Gaskets | stainless steel A2 |
| Bolts | galvanized iron |
| STAINER | 20 m |
| Title | Description |
|---|---|
| 2 poles induction motor in oil bath | 3~ 220/380V-60Hz, 1~ 220V-60Hz |
| Insulation class | F |
| Protection degree | IP68 |
